8080MK-A-01-E1-00-0

Series: 8080MK Model Loop Powered Indicator Brand: International Metal Engineering (IME)

IME Model 8080 Process Indicator LED Display, Aluminium, M16x2P, 4-20 mA, 2-Wire, 4 digit LED, CSA

Price
$708.27USD
Stock
4 - 6 weeks
Request Information

  • LED Indicator, 4 Digits, 0.5" Tall Characters
  • 4-20 mA Input
  • 2-Wire Loop Powered
  • (2) 3/4" FNPT Conduit Connection
  • (1) M16 x 2P Mounting Only Connection (Bottom)
  • -40C to +60C Operating Temperature
  • 0.1 Watt Power Consumption
  • 5 V Voltage drop
  • CSA, Explosion Proof Class 1, Division1, Groups C,D

  • LED Indicator, 4 Digits, 0.5" Tall Characters
  • 4-20 mA Input
  • 2-Wire Loop Powered
  • (2) 3/4" FNPT Conduit Connection
  • (1) M16 x 2P Mounting Only Connection (Bottom)
  • -40C to +60C Operating Temperature
  • 0.1 Watt Power Consumption
  • 5 V Voltage drop
  • CSA, Explosion Proof Class 1, Division1, Groups C,D
Close

Specifications

Brand

Accuracy

  • ± 0.5° C (± 0.9° F)

Alarm

  • 2 Sets SPDT, Rated 10 A at 250 Vac, 50/60 Hz
  • None

Approvals & Certifications

  • ATEX
  • CSA
  • FM
  • IEC Ex

Conduit Connection

  • 1/2” NPT
  • 3/4” NPT
  • M20 x 1.5

Digital Stability

  • 0.1 % of Calibrated Range ± 1-Digit over 6 Months

Display

  • 4-Digit LED

Enclosure, Body Material

  • 316 Stainless Steel
  • Aluminum, Epoxy Coated

Environmental Protection

  • IP66
  • NEMA 4X / IP66

Input

  • 4-20 mA

Instrument Connection

  • 1/2” NPT
  • M16 x 2P

Mounting

  • 2” U-Bolt Fasteners for Pipe Mounting
  • 316 Stainless Steel Mounting Kit, for Wall or 2” Pipe
  • 316 Stainless Steel Wall Mounting Bracket

Response Time

  • Typically 20 to 75 milliseconds

Supply Voltage

  • Loop Powered

Temperature Range

  • -40° to 60° C (-40° to 140° F)
