PDA6854 Panel Mounting Kit for PD685

Brand: Precision Digital Corporation
The PDA6854 is a panel mounting kit for the PD685. It provides all of the necessary hardware to mount the PD685 meter to an equipment panel.

This panel mounting kit is not intended to provide waterproof protection to the panel.

Parts Supplied:
  • One mounting plate (ABS plastic)
  • Four self tapping screws
  • Four mounting brackets
  • Twelve washers
show more
Images are representations only.
The PDA6854 is a panel mounting kit for the PD685. It provides all of the necessary hardware to mount the PD685 meter to an equipment panel.

This panel mounting kit is not intended to provide waterproof protection to the panel.

Parts Supplied:
  • One mounting plate (ABS plastic)
  • Four self tapping screws
  • Four mounting brackets
  • Twelve washers

Specifications

Panel Cutout Required

  • 5.04” x 3.07” (128 x 78)

Mounting Plate Overall Dimensions

  • 6.02” 4.05” x 0.125” (153 x 103 x 3)

Allowable Panel Thickness

  • 0.060" – 0.125" (1.5 – 3.2)

Weight lb (kg)

  • 0.2 (0.1)
