Vegabar 14 Pressure Transmitter

Brand: VEGA
Request Information
Favorite
The VEGABAR 14 pressure transmitter can be used universally for measurement of gases, vapours and liquids.

The small pressure transmitter offers maximum reliability.

The VEGABAR 14 is an economical solution for a multitude of applications in all areas of industry.
Features
  • High Plant Availability through Maximum Overload and Vacuum Resistance of the Ceramic Measuring Cell
  • Low-Cost Version with Very Small Mounting Dimensions
  • Low Costs for Maintenance thanks to Wear-Free Ceramic Measuring Cell
show more
The VEGABAR 14 pressure transmitter can be used universally for measurement of gases, vapours and liquids.

The small pressure transmitter offers maximum reliability.

The VEGABAR 14 is an economical solution for a multitude of applications in all areas of industry.
Features
  • High Plant Availability through Maximum Overload and Vacuum Resistance of the Ceramic Measuring Cell
  • Low-Cost Version with Very Small Mounting Dimensions
  • Low Costs for Maintenance thanks to Wear-Free Ceramic Measuring Cell
Close
Close

Specifications

Brand

Accuracy

  • 0.3%

Ambient Temperature Range

  • -40° to 80° C (-40° to 176° F)

Applications

  • Gases
  • Liquids

Approvals & Certifications

  • ATEX

BSP Connection

  • G 1/2” Male

Cable Entry

  • M12 x 1

Cable Length

  • 16.4 to 328.1 feet (5 to 100 metres)

Environmental Protection

  • IP65
  • IP67
  • IP68

NPT Connection

  • 1/2” NPT Male

Operating Voltages

  • 12-36 Vdc

Output

  • 4-20 mA

Pressure Range

  • bar: -1 to 60
  • kPa: -100 to 6,000
  • psig: -14.5 to 870

Pressure Type

  • Gauge

Process Temperature

  • -40° to 100° C (-40° to 212° F)

Seat / Seal Material

  • EPDM
  • FFKM
  • FKM

Storage Temperature

  • -40° to 80° C (-40° to 176° F)

Wetted Materials

  • 316L Stainless Steel
  • Duplex
  • PVDF
  • Sapphire-Ceramic
