F030 Batch Controller

Brand: Precision Digital Corporation
Request Information
Favorite
The F030 is a straight forward but easy-to-use batch controller.

The operator can easily enter a batch quantity or execute repeating batches.

During the batch, the preset value is displayed as well as the batched or remaining quantity.

The automatic self-learning overrun correction will ensure an accurate batch every time.

On-screen engineering units are easily configured from a comprehensive selection.
Features
  • Large display shows preset value and running batch value simultaneously.
  • Self-learning overrun correction.
  • One control output to drive a valve or pump.
  • Easy operation to enter a batch value and to control the process.
  • Count-up and count-down function available.
  • Green or amber LED backlight with adjustable intensity.
  • Actual batched quantity: seven 17 mm (0.67") digits.
  • Preset value: seven 17 mm (0.67") digits during programming and 8 mm (0.31") digits during process.
  • Total - resettable: seven 17 mm (0.67") digits.
  • Accumulated total - not resettable: eleven 8 mm (0.31") digits.
  • Selectable on-screen engineering units for totalizer: ml, L, m³, GAL, USGAL, kg, lb, bbl or no unit.
  • Auto backup of settings and running totals in EEPROM memory.
  • Easy configuration with clear alphanumerical display.
  • Ambient temperature: -40° to +80° C (-40° to 176° F).
show more
The F030 is a straight forward but easy-to-use batch controller.

The operator can easily enter a batch quantity or execute repeating batches.

During the batch, the preset value is displayed as well as the batched or remaining quantity.

The automatic self-learning overrun correction will ensure an accurate batch every time.

On-screen engineering units are easily configured from a comprehensive selection.
Features
  • Large display shows preset value and running batch value simultaneously.
  • Self-learning overrun correction.
  • One control output to drive a valve or pump.
  • Easy operation to enter a batch value and to control the process.
  • Count-up and count-down function available.
  • Green or amber LED backlight with adjustable intensity.
  • Actual batched quantity: seven 17 mm (0.67") digits.
  • Preset value: seven 17 mm (0.67") digits during programming and 8 mm (0.31") digits during process.
  • Total - resettable: seven 17 mm (0.67") digits.
  • Accumulated total - not resettable: eleven 8 mm (0.31") digits.
  • Selectable on-screen engineering units for totalizer: ml, L, m³, GAL, USGAL, kg, lb, bbl or no unit.
  • Auto backup of settings and running totals in EEPROM memory.
  • Easy configuration with clear alphanumerical display.
  • Ambient temperature: -40° to +80° C (-40° to 176° F).
Close
Close

Specifications

Brand

Accuracy

  • ± 0.05% of Full Scale Output

Approvals & Certifications

  • ATEX
  • CE
  • CSA
  • EMC
  • FM
  • IEC
  • IEC Ex

Conduit Connection

  • 1/2" NPT
  • M12
  • M16
  • M20
  • PG9

Display

  • 0.67"

Electrical Connectors

  • Removable Plug-in Terminal Strip

Enclosure, Body Material

  • Aluminum
  • Fiberglass
  • PolyCarbonate Window
  • Silicone Sealing

Environmental Protection

  • IP65
  • IP67
  • NEMA 4X / IP65, 67

Function

  • Linear
  • Square Root

Input

  • 0-10 Vdc
  • 4-20 mA

K-Factor

  • Programmable from 0.0001 to 99999

Load Impedance

  • 3,000 ohms Minimum

Operating Temperature

  • -40° to 80° C (-40° to 176° F)

Power

  • 115-230 Vac
  • 8-24 Vac/Vdc

Resolution

  • 16-bits

Voltage Drop

  • 1 V at 20 mA
  • 2.6 V @ 20 mA (Loop Powered)
