Images are representations only.

88 Series Manual Ball Valve

Brand: A-T Controls, Inc.
Features
  • Design: 3-Piece High Performance, Direct Mount, Locking Handle
  • Size: 1/4", 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2", 2-1/2", 3", 4"
  • Port: Full
  • Direct Mount: Yes
  • Pyramidal Stem Packing: Yes
  • Materials of Construction:
    • Body: 316 Stainless Steel, WCB
    • Trim: 316 Stainless Steel
    • Available Seats: RTFE, PTFE, 50/50%, TFM-1600, MG1241, UHMWPE, PEEK, Cavity Filled
  • End Connections: Threaded Ends, Socket Weld, Butt Weld
  • Maximum Pressure Rating: psig: 1,000 to 2,000
show more
Features
  • Design: 3-Piece High Performance, Direct Mount, Locking Handle
  • Size: 1/4", 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2", 2-1/2", 3", 4"
  • Port: Full
  • Direct Mount: Yes
  • Pyramidal Stem Packing: Yes
  • Materials of Construction:
    • Body: 316 Stainless Steel, WCB
    • Trim: 316 Stainless Steel
    • Available Seats: RTFE, PTFE, 50/50%, TFM-1600, MG1241, UHMWPE, PEEK, Cavity Filled
  • End Connections: Threaded Ends, Socket Weld, Butt Weld
  • Maximum Pressure Rating: psig: 1,000 to 2,000
31 models matching criteria
88C-TS-0050-XXX
A-T CONTROLS Series 88 Ball Valve, 3-Piece Carbon, Threaded, 1/2", RTFE View More
  • 88: 3-Piece High Performance, Direct Mount, 2000/1500/1000 WOG, Full Port
  • C: Carbon Steel Body
  • TS: Threaded x Socket Weld
  • 0050: 1/2" Valve Size
  • X: Reinforced TFE Seats (RTFE)
  • XX: No Specials
  • Pyramidal Stem Packing: Yes
  • Maximum Pressure Rating: 2000 psi
2 - 4 weeks
$93.08 USD
$15.51 Shipping
88-TS-0050-XXX
A-T CONTROLS Series 88 Ball Valve, 3-Piece Threaded, 1/2", SST, RTFE View More
  • 88: 3-Piece High Performance, Direct Mount, 2000/1500/1000 WOG, Full Port

    • SST Body and Trim
  • TS: Threaded x Socket Weld
  • 0050: 1/2" Valve Size
  • X: Reinforced TFE Seats (RTFE)
  • XX: No Specials
  • Pyramidal Stem Packing: Yes
  • Maximum Pressure Rating: 2000 psi
2 - 4 weeks
$104.72 USD
$15.51 Shipping
88-TH-0050-XXX
A-T CONTROLS Series 88 Ball Valve, 3-Piece Threaded, 1/2", RTFE View More
  • 88: 3-Piece High Performance, Direct Mount, 2000/1500/1000 WOG, Full Port

    • SST Body and Trim
  • TH: NPT Ends
  • 0050: 1/2" Valve Size
  • X: Reinforced TFE Seats (RTFE)
  • XX: No Specials
  • Pyramidal Stem Packing: Yes
  • Maximum Pressure Rating: 2000 psi
2 - 4 weeks
$120.23 USD
$15.51 Shipping
88C-TS-0075-XXX
A-T CONTROLS Series 88 Ball Valve, 3-Piece Carbon, Threaded, 3/4", RTFE View More
  • 88: 3-Piece High Performance, Direct Mount, 2000/1500/1000 WOG, Full Port
  • C: Carbon Steel Body
  • TS: Threaded x Socket Weld
  • 0075: 3/4" Valve Size
  • X: Reinforced TFE Seats (RTFE)
  • XX: No Specials
  • Pyramidal Stem Packing: Yes
  • Maximum Pressure Rating: 2000 psi
2 - 4 weeks
$121.78 USD
$15.51 Shipping
88-TH-0075-XXX
A-T CONTROLS Series 88 Ball Valve, 3-Piece Threaded, 3/4", RTFE View More
  • 88: 3-Piece High Performance, Direct Mount, 2000/1500/1000 WOG, Full Port

    • SST Body and Trim
  • TH: NPT Ends
  • 0075: 3/4" Valve Size
  • X: Reinforced TFE Seats (RTFE)
  • XX: No Specials
  • Pyramidal Stem Packing: Yes
  • Maximum Pressure Rating: 2000 psi
2 - 4 weeks
$134.97 USD
$15.51 Shipping
88-TS-0075-XXX
A-T CONTROLS Series 88 Ball Valve, 3-Piece Threaded, 3/4", SST, RTFE View More
  • 88: 3-Piece High Performance, Direct Mount, 2000/1500/1000 WOG, Full Port

    • SST Body and Trim
  • TS: Threaded x Socket Weld
  • 00750: 3/4" Valve Size
  • X: Reinforced TFE Seats (RTFE)
  • XX: No Specials
  • Pyramidal Stem Packing: Yes
  • Maximum Pressure Rating: 2000 psi
2 - 4 weeks
$134.97 USD
$15.51 Shipping
88-TH-0050-SXX
A-T CONTROLS Series 88 Ball Valve, 3-Piece Threaded, 1/2", 50/50 (SST/PTFE) Seats View More
  • 88: 3-Piece High Performance, Direct Mount, 2000/1500/1000 WOG, Full Port

    • SST Body and Trim
  • TH: NPT Ends
  • 0050: 1/2" Valve Size
  • S: 50/50 STFE Seats
  • XX: No Specials
  • Pyramidal Stem Packing: Yes
  • Maximum Pressure Rating: 2000 psi



2 - 4 weeks
$137.30 USD
$15.51 Shipping
88C-TH-0100-XXX
A-T CONTROLS Series 88 Ball Valve, 3-Piece Carbon, Threaded, 1", RTFE View More
  • 88: 3-piece Direct Mount 2000/1500 WOG, Full Port

    • Pyramidal Stem Packing, Locking Handle
  • C: Carbon Steel Body
  • TH: NPT Ends
  • 0100: 1" Valve Size
  • X: Reinforced TFE Seats (RTFE)
  • XX: No Specials
2 - 4 weeks
$162.12 USD
$15.51 Shipping
88-V60-0050-BALL
A-T CONTROLS Series 88 Control Port Ball Valves, 1/2", 50/50 (SST/PTFE) Seats, Ball View More
  • Design: 3pc. High performance, Direct mount, Locking Handle
  • Size: 1/2" NPT
  • Port: Full
  • Direct Mount: Yes
  • Pyramidal Stem Packing: Yes
  • Materials of Construction:
    • Body: 316 Stainless Steel
    • Trim: 316 Stainless Steel
    • Available Seats: 50% Stainless Steel Powder Filled TFE
  • End Connections: Threaded
  • Maximum Pressure Rating: 2000/1500 psi
  • Options: Vented Ball
2 - 4 weeks
$162.12 USD
$15.51 Shipping
88-V60-0500-BALL
A-T CONTROLS Series 88 Control Port Ball Valves, 1/2", 50/50 (SST/PTFE) Seats, Ball View More
  • Design: 3pc. High performance, Direct mount, Locking Handle
  • Size: 1/2" NPT
  • Port: Full
  • Direct Mount: Yes
  • Pyramidal Stem Packing: Yes
  • Materials of Construction:
    • Body: 316 Stainless Steel
    • Trim: 316 Stainless Steel
    • Available Seats: 50% Stainless Steel Powder Filled / 50% TFE
  • End Connections: Threaded
  • Maximum Pressure Rating: 2000/1500 psi
  • Options: Vented Ball
2 - 4 weeks
$162.12 USD
$15.51 Shipping

Specifications

Direct Mount

  • Yes

Enclosure, Body Material

  • 316 Stainless Steel
  • WCB Carbon Steel

NPT Connection

  • 1" NPT Female
  • 1/2" NPT Female
  • 1/4" NPT Female
  • 1-1/2" NPT Female
  • 1-1/4" NPT Female
  • 2" NPT Female
  • 2-1/2" NPT Female
  • 3" NPT Female
  • 3/4" NPT Female
  • 3/8" NPT Female
  • 4" NPT Female

Options

  • Cleaned for Oxygen
  • Degrease & Bagged
  • Gear Operator
  • Oval Handle
  • Vented Ball

Port

  • Full

Pressure Rating

  • psig: 1,500 to 2,000

Pyramidal Stem Packing

  • Yes

Seat / Seal Material

  • 50% Stainless Steel Powder / 50% Carbon Filled Teflon
  • Cavity Filled
  • MG1241
  • PEEK®
  • PTFE (Carbon Filled Teflon)
  • RTFE (Reinforced Teflon)
  • TFM-1600
  • UHMWPE

TA-Luft Certified

  • Yes

Valve Type

  • Manual

Welded Connection

  • 1" Butt Weld End
  • 1" Socket Weld End
  • 1/2" Butt Weld End
  • 1/2" Socket Weld End
  • 1/4" Butt Weld End
  • 1/4" Socket Weld End
  • 1-1/2" Butt Weld End
  • 1-1/2" Socket Weld End
  • 1-1/4" Butt Weld End
  • 1-1/4" Socket Weld End
  • 2" Butt Weld End
  • 2" Socket Weld End
  • 2-1/2" Butt Weld End
  • 2-1/2" Socket Weld End
  • 3" Butt Weld End
  • 3" Socket Weld End
  • 3/4" Butt Weld End
  • 3/4" Socket Weld End
  • 3/8" Butt Weld End
  • 3/8" Socket Weld End
  • 4" Butt Weld End
  • 4" Socket Weld End
