JJ06 Pilot & Mechanical Valve

Brand: Bifold Group
Features:
  • 316L stainless steel
  • Arctic service options to -60° C (-76° F)
  • Air, sweet & sour gases, hydraulic oil
show more
Features:
  • 316L stainless steel
  • Arctic service options to -60° C (-76° F)
  • Air, sweet & sour gases, hydraulic oil

Specifications

Brand

Actuator Type

  • Spring Return

Adjustment Type

  • Pull Button
  • Push Button

BSP Connection

  • 1/4" BSPP Female

Configuration

  • 2-Way, 2-Position
  • 3-Way, 2-Position
  • 5-Port, 2-Position

Electrical Contacts

  • Normally Closed

Enclosure, Body Material

  • 316L Stainless Steel

Flow Capacity

  • 0.7 Cv - for 1-2
  • 0.9 Cv - for 2-3
  • 25 scfm (42.5 m³/hour) (12 Nl/second) (708 Nl/Minute) - for 1-2
  • 32 scfm (54.36 m³/hour) (15 Nl/second) (906 Nl/Minute) - for 2-3

Indication

  • Eyeball Indicator (Green ON, Red OFF)

Materials of Construction

  • Metric A4 18/10 316 Stainless Steel - Fasteners

Media

  • Air
  • Hydraulic Oil
  • Sweet & Sour Gas

Mounting

  • Panel Mount

NPT Connection

  • 1/4" NPT Female

Operating Pressure

  • psi: 0 to 116 (kPa: 0 to 800, bar: 0 to 8) - ASJJE/AHSJJE
  • psi: 0 to 145 (kPa: 0 to 1,000, bar: 0 to 10) - Standard Service

Seat / Seal Material

  • Seat: Viton

Spring Material

  • 316L Stainless Steel

Switch Type

  • Proximity

Temperature Range

  • -20° to 180° C (-4° to 356° F) - SJJE/HSJJE
  • -60° to 40° C (-76° to 104° F) - ASJJE/AHSJJE
