1750 Series Plunger/Roller Lever Operated

Brand: Midland-ACS
A range of 3/2 mechanically operated Poppet Valves for cylinder position detection in 316L Stainless Steel for use on gases.
Features
  • Specifically Designed for Severe Environments
  • Ambient Temperature Range -20° to 80° C (-4° to 176° F)
  • 316L Stainless Steel Construction
  • Mechanically Operated
  • Limit Switch for End of Actuator Stroke Detection
show more
A range of 3/2 mechanically operated Poppet Valves for cylinder position detection in 316L Stainless Steel for use on gases.
Features
  • Specifically Designed for Severe Environments
  • Ambient Temperature Range -20° to 80° C (-4° to 176° F)
  • 316L Stainless Steel Construction
  • Mechanically Operated
  • Limit Switch for End of Actuator Stroke Detection

Specifications

Brand

Actuator Type

  • Lever Roller Operated
  • Plunger Operated

Ambient Temperature Range

  • -20° to 80° C (-4° to 176° F)

Approvals & Certifications

  • ATEX
  • CE
  • EAC

Enclosure, Body Material

  • 316L Stainless Steel

Flow Capacity

  • 0.26 Cv
  • 14.2 scfm (24.14 m³/hour)

Flow Rate

  • 402 L/minute at 6.0 bar with 1.0 bar Differential

Media

  • Filtere Lubricated or Non-Lubricated Air
  • Inert Gas
  • Liquids - Low Pressure Hydraulic, Mineral Oil or Water
  • Sour Natural Gas
  • Sweet Natural Gas

NPT Connection

  • 1/8" NPT Female

Seat / Seal Material

  • Nitrile

Spring Material

  • 316 Stainless Steel

Supply Pressure - Maximum

  • bar: 12
  • kPa: 1,200
  • psi: 145

Trim Material

  • 316L Stainless Steel
