Ultra-High Temperature Pasteurization (UHT) Thermowell

Brand: Pyromation
Request Information
Favorite
The VCB series thermowells are intended to be used in high pressure UHT process lines. They are installed by welding the 3/8” OD sleeve directly into the sanitary tubing.

The thermowells are made of 316 SS and the wetted parts are supplied with a surface finish that meets or exceeds 32μin Ra.

Surface finishes of 15μin Ra or better are available upon request.

These thermowells are supplied with a 9/16” -18 UNF-2A female rotating instrument connection with weep hole for leak detection.
show more
The VCB series thermowells are intended to be used in high pressure UHT process lines. They are installed by welding the 3/8” OD sleeve directly into the sanitary tubing.

The thermowells are made of 316 SS and the wetted parts are supplied with a surface finish that meets or exceeds 32μin Ra.

Surface finishes of 15μin Ra or better are available upon request.

These thermowells are supplied with a 9/16” -18 UNF-2A female rotating instrument connection with weep hole for leak detection.
Close
Close

Specifications

Brand

Bore Size

  • 0.134", 0.194"

Process Connection

  • 9/16"-18 UNF-2A

Enclosure / Body Material

  • 316 stainless steel
