Ring Thermocouple

Brand: Pyromation
The ring type assemblies pictured below have the thermocouples embedded either into a stainless steel stamping for grounded junctions (figure 1) or a brass ring for ungrounded junctions (figure 2).

Various ring sizes are available to measure the surface temperature of nozzles, extruder barrels, die heads, molds, and many other applicable surfaces.
show more
The ring type assemblies pictured below have the thermocouples embedded either into a stainless steel stamping for grounded junctions (figure 1) or a brass ring for ungrounded junctions (figure 2).

Various ring sizes are available to measure the surface temperature of nozzles, extruder barrels, die heads, molds, and many other applicable surfaces.

Specifications

Brand

Ring Material

  • Brass
  • Stainless steel

Thermocouple Type

  • Type J, E, K, T

Leadwire Insulation

  • Fiberglass
  • Polyimide
  • Fluoropolymer
