Images are representations only.

OPTION-AO J/C/C6/T Signal for Load Cell & Torque Meter

Brand: Sensy S.A.
The option converts the signal from the Wheatstone bridge (mV/V) in a robust industrial standardized 4 to 20 mA signal.
Features
  • Internal or external mounting depending of the size of the transducer
  • If external: cylindrical housing in nickel plated brass or rectangular box in Aluminum (low-cost version)
  • Protection:
    • Cylindrical housing: IP 67
    • Rectangular box: IP 65
  • Available version with shifted zero for bidirectional utilization for versions 4 to 20 mA and 0-10 V
  • Version 2-Wires: protection against wrong cabling
show more
The option converts the signal from the Wheatstone bridge (mV/V) in a robust industrial standardized 4 to 20 mA signal.
Features
  • Internal or external mounting depending of the size of the transducer
  • If external: cylindrical housing in nickel plated brass or rectangular box in Aluminum (low-cost version)
  • Protection:
    • Cylindrical housing: IP 67
    • Rectangular box: IP 65
  • Available version with shifted zero for bidirectional utilization for versions 4 to 20 mA and 0-10 V
  • Version 2-Wires: protection against wrong cabling

Specifications

Brand

Applications

  • Industrial Applications
  • Load & Compression Sensing
  • Overhead Travelling Cranes
  • Torque Measurement

Approvals & Certifications

  • ATEX
  • CE
  • CSA
  • IECEx

Bandwidth

  • 0 to 1,000 Hz

Consumption

  • ≤ 23 mA
  • ≤ 25 mA
  • Maximum

Enclosure, Body Material

  • Aluminum
  • Nickel-Plated Brass

Environmental Protection

  • IP65 - Rectangular Box
  • IP67 - Cylindrical Housing

Housing Style

  • Cylindrical Housing
  • Rectangular Box

Input

  • 0.5 - 5.5 mV/V

Load Impedance

  • 350 to 5,000 ohms - Impedance of Wheatstone Bridge

Measuring Error

  • <± 0.02% of Full Scale - Combined Error

Mounting

  • Universal Internal or External

Output

  • -10-10 V (11, Maximum
  • 4-20 mA (24, Maximum

Resistance

  • ≤ 750 to > 10,000 ohms

Sensor Excitation

  • 0.5 to 8 Vdc

Service Temperature

  • -40° to 85° C (-40° to 185° F)

Supply Voltage

  • 9 to 30 Vdc

Temperature Coefficient

  • <± 0.025% of Full Scale/10° C (18° F)
  • <± 0.05% of Full Scale/10° C (18° F)
  • <± 0.064% of Full Scale/10° C (18° F)
  • <± 0.065% of Full Scale/10° C (18° F)
  • <± 0.14% of Full Scale/10° C (18° F)

Temperature Range

  • -10° to 45° C (14° to 113° F) - Nominal
