Wellhead Grease Fittings, Combination Lubricant Stick Injector Series

Brand: PGI International
Parker PGI's Combination and Stick Injector Grease Fittings feature a heavy-duty radial rivet crimp. This special crimp provides the best "blow-out" protection of any available crimped style fitting. The radial rivet crimp process conforms to the latest revision of NACE when manufactured with 316 SS or 4140 body material.
Features
  • Accepts Button head Coupler
  • Heavy Duty Radial Rivet Crimp
  • 316 SS and 1215 Material available
show more
Images are representations only.
Parker PGI's Combination and Stick Injector Grease Fittings feature a heavy-duty radial rivet crimp. This special crimp provides the best "blow-out" protection of any available crimped style fitting. The radial rivet crimp process conforms to the latest revision of NACE when manufactured with 316 SS or 4140 body material.
Features
  • Accepts Button head Coupler
  • Heavy Duty Radial Rivet Crimp
  • 316 SS and 1215 Material available

Combination Lubricant Stick Injector Series

Seat Style

Thread Type

Process Connection

Material

Specifications

Product Style

  • Single Ball Check
  • Double Ball Check

Connection Thread Size

  • 1/4" - 3/4" (NPSM), 3/8" - 1" (UNC)

Body Material

  • Consult Factory for Additional Materials
  • 316 Stainless Steel
  • 1215

Plating Type

  • N/A
  • Zinc

Heat Treatment

  • N/A
  • Annealed (NACE)

Ball Material

  • Consult Factory for Additional Materials
  • K-MonelĀ®
  • AISI 52100 Chrome Alloy

Spring Material

  • Consult Factory for Additional Materials
  • InconelĀ® X-750
  • 302 Stainless Steel

Length

  • 1-1/2" - 4-3/4"

Maximum Operating Pressure

  • 10000 PSI
  • 689 Bar

Typical Applications

  • Wellhead Lube Systems
