1750 Series Pilot-Operated

Brand: Midland-ACS
Request Information
Favorite
A range of 3/2 pilot operated poppet valves in stainless steel 316L for use on gases.
Features
  • Specifically Designed for Severe Environments
  • Ambient Temperature Range -20° to 180 C (-4° to 356° F)
  • 316L Stainless Steel Construction
  • Designed for Actuator Control
  • Large Flow Paths (Up to 110 Cv)
show more
A range of 3/2 pilot operated poppet valves in stainless steel 316L for use on gases.
Features
  • Specifically Designed for Severe Environments
  • Ambient Temperature Range -20° to 180 C (-4° to 356° F)
  • 316L Stainless Steel Construction
  • Designed for Actuator Control
  • Large Flow Paths (Up to 110 Cv)
Close

Displaying prices & availability for United States in USD. Change location or currency

MIDLAND-ACS 4500 Series Non-Return Valve
MIDLAND-ACS 4500 Series Non-Return Valve View More
316L Stainless Steel non-return valves for pressures up to 174 psi and 391 psi.



Features and Benefits:

  • Specifically Designed for Severe Environments
  • Ambient Temperature Range -20º to 70º C (-4° to 158° F)
  • Low Temperature option available
  • 316L Stainless Steel
Out of Stock
$511.64USD
$19.00 Shipping
6325M21-SC2B
MIDLAND-ACS Series 1750 Poppet Valve, up to 110 Cv, 3/4" Pilot Operated, 3/2 View More
  • Version: 3/4" 3/2 Pilot Operated Spring Return
  • Construction: 316L Stainless Steel, Fluoroelastomer
  • Cv: 8
  • Max Flow L/Min: 8041 (284 SCFM)
  • Min Pilot Pressure: 3.0 bar
  • Max Working Pressure: 12 bar (174 psi)
  • Working Temperature: -20°C to +180°C (-4°F to +356°F)
5 - 6 weeks
$1,290.06USD
$19.00 Shipping
MIDLAND-ACS 4500 Series Shuttle Valve
MIDLAND-ACS 4500 Series Shuttle Valve View More
316L Stainless Steel Shuttle Valves for Three-Way "OR" Function.



Features and Benefits:

  • Specifically Designed for Severe Environments
  • Ambient Temperature Range -20º to 70º C (-4° to 158º F)
  • Low temperature option available
  • 316L Stainless Steel
  • 5 sizes available
Out of Stock
Close
Close

Specifications

Brand

Ambient Temperature Range

  • -20° to 180° C (-4° to 356° F)

Approvals & Certifications

  • ATEX
  • CE
  • EAC

Enclosure, Body Material

  • 316L Stainless Steel

Flow Capacity

  • 1” to 13 Cv, 454 scfm (771.96 m³/hour)
  • 1/2” - 3.5 Cv, 124 scfm (210.68 m³/hour)
  • 1/4” - 1.2 Cv, 43 scfm (72.96 m³/hour)
  • 1-1/2” - 26 Cv, 923 scfm (1342.7 m³/hour)
  • 1-1/4”-18 Cv, 624 scfm (1059 m³/hour)
  • 2” - 50 Cv, 1797 scfm (3051.6 m³/hour)
  • 3” - 110 Cv (90 Offset Ports) 3954 scfm (237.24 m³/hour)
  • 3/4” - 8 Cv, 284 scfm (482.46 m³/hour)
  • 3/8” - 1.8 Cv, 64 scfm (108.6 m³/hour)

Media

  • Air
  • Filtered Lubricated or Non-Lubricated Air, Inert Gas, Sweet (Natural) & Sour Gases
  • Liquids - Low Pressure Hydraulic, Mineral Oil or Water

NPT Connection

  • 1” NPT Female
  • 1/2” NPT Female
  • 1/4” NPT Female
  • 1-1/2” NPT Female
  • 1-1/4” NPT Female
  • 2” NPT Female
  • 3” NPT Female
  • 3/4” NPT Female
  • 3/8” NPT Female

Pilot Pressure

  • psi: 43.5 to 58 (kPa: 300 to 400, bar: 3 to 4)

Seat / Seal Material

  • 1/4” to 1-1/2” Fluoroelastomer (Standard Option)
  • 1/4” to 2” EPDM (Low Temperature Version)
  • 2” & 3” Nitrile (Standard Option)

Spring Material

  • 316 Stainless Steel

Supply Pressure - Maximum

  • bar: 12
  • kPa: 1,200
  • psi: 174

Trim Material

  • 316L Stainless Steel
