Model 17 Vacuum Regulator

Brand: Fairchild Industrial Products
The Rotork Fairchild Model 17 Vacuum Regulator is designed for systems that require system vacuum control up to full vacuum. The Model 17 control diaphragm is balanced by a set of three range springs to provide the most stable, responsive and reliable operation. Stability of regulated vacuum or pressure is maintained under varying flow conditions through the use of an aspirator tube which adjusts the inner valve in accordance with the flow velocity.

The Model 17 pneumatic vacuum regulator features control sensitivity of 1/2" water column and a balanced supply valve to deliver consistent and reliable precision accuracy to maintain your desired set point regardless of supply pressure changes or conditions. In fact, it will deliver this performance with a vacuum supply effect of less than 0.15 of any change in supply vacuum.

The Fairchild Model 17 will handle a 40 in Hg, 762 Torr, 102 kPa maximum supply vacuum and offers three (3) output vacuum ranges from 0-5 in Hg, 0-127 Torr, 0-17 kPa, up to 0-30 in Hg, 0-762 Torr, 0-102 kPa. The Fairchild Model 17 pneumatic vacuum regulator offers up to 12 SCFM, 20.4 m3/hr flow capacity.
Features
  • Full vacuum capability
  • Control sensitivity of 1/2" water column
  • High flow capacity
  • Balanced vacuum Valve
  • Aspirator Tube
  • Separate Control Chamber
  • Unit construction
show more
The Rotork Fairchild Model 17 Vacuum Regulator is designed for systems that require system vacuum control up to full vacuum. The Model 17 control diaphragm is balanced by a set of three range springs to provide the most stable, responsive and reliable operation. Stability of regulated vacuum or pressure is maintained under varying flow conditions through the use of an aspirator tube which adjusts the inner valve in accordance with the flow velocity.

The Model 17 pneumatic vacuum regulator features control sensitivity of 1/2" water column and a balanced supply valve to deliver consistent and reliable precision accuracy to maintain your desired set point regardless of supply pressure changes or conditions. In fact, it will deliver this performance with a vacuum supply effect of less than 0.15 of any change in supply vacuum.

The Fairchild Model 17 will handle a 40 in Hg, 762 Torr, 102 kPa maximum supply vacuum and offers three (3) output vacuum ranges from 0-5 in Hg, 0-127 Torr, 0-17 kPa, up to 0-30 in Hg, 0-762 Torr, 0-102 kPa. The Fairchild Model 17 pneumatic vacuum regulator offers up to 12 SCFM, 20.4 m3/hr flow capacity.
Features
  • Full vacuum capability
  • Control sensitivity of 1/2" water column
  • High flow capacity
  • Balanced vacuum Valve
  • Aspirator Tube
  • Separate Control Chamber
  • Unit construction
4 models matching criteria
17112NNKN
FAIRCHILD Model 17 Vacuum Regulator, 1/4" NPT, Nitrile, 0-5 in Hg, Knob Assembly, Non-Relieving
8 - 12 days
$752.99USD
$16.15 Shipping
17132NNKN
FAIRCHILD Model 17 Vacuum Regulator, 1/4" NPT, 0-30 In. Hg, Nitrile, Knob, NR
8 - 12 days
$752.99USD
$16.15 Shipping
17132NNKR
FAIRCHILD Model 17 Vacuum Regulator, 1/4" NPT, 0-30 In. Hg
2 - 4 weeks
$786.12USD
$16.15 Shipping
17124N
FAIRCHILD Model 17 Vacuum Regulator, 1/2" NPT, 0-15 In. Hg
2 - 4 weeks

Specifications

Actuator Type

  • Knob Assembly
  • Tamper-Proof

Ambient Temperature Range

  • -40° to 93.3° C (-40° to 200° F)

BSP Connection

  • 1/2" BSPP Female
  • 1/2" BSPT Female
  • 1/4" BSPP Female
  • 1/4" BSPT Female
  • 3/8" BSPP Female
  • 3/8" BSPT Female

Diaphragm Material

  • Buna-N on Dacron (Standard Unit Only)

Elastomers

  • FluoroCarbon
  • Nitrile

Enclosure, Body Material

  • Aluminum Housing

Environmental Protection

  • Acceptable for use in Zones 1 & 2 for Gas Atmosphere, Groups IIA & IIB & Zones 21 & 22 for Dust Atmospheres

Exhaust Capacity - Relieving Units Only

  • 2.0 scfm (3.4 m³/hour)

Flow Capacity

  • 12 scfm (20.4 m³/hour)

Mounting

  • Bracket Kit

NPT Connection

  • 1/2" NPT Female
  • 1/4" NPT Female
  • 3/8" NPT Female

Pressure Range

  • bar: 0.17 to 1.02
  • Inches Hg: 0 to 30
  • kPa: 17 to 102
  • psi: 2.5 to 14.8

Relief

  • Non-Relieving
  • Relieving

Supply Pressure Effect

  • less than 0.1% of Change in Supply Vacuum

Trim Material

  • Stainless Steel
  • Zinc-Plated Steel
