Description
- Media: Water, Oil, Air
- Media Temperature: -10° to 90° C (14° to 194° F)
- Ambient temperature: -10° to 50° C (14° to 122° F)
- Body Material: Brass (CW617N EN 12165)
- Operator Material: Stainless Steel
- Operator Seal Material and Diaphragm Material: NBR
- Protection Class: IP65 (with Connector and Gasket)
Specifications
Specifications
Approvals & Certifications
- CE
- UL Approved Coils
BSP Connection
- G 1” Female
- G 1/2” Female
- G 1/4” Female
- G 3/4” Female
- G 3/8” Female
Enclosure, Body Material
- Brass (CW617N EN 12165)
Environmental Protection
- IP65 (with Connector & Gasket)
Seat / Seal Material
- Operator Seal: NBR
- Seal: EPDM, Temperature, Max.
- Seal: FKM, Temperature, Max.
