Description
Heavy-duty limit switch boxes, designed for hazardous areas, provide a visual and electrical remote position feedback on automated valves.
Available in either copper free aluminum or 316 stainless steel, the explosion proof enclosure matches the Ex d IIC T6 standards. The SY - SW limit switch box series, thanks to its large inner volume able to host up to 6 switches and spare pass through terminals and the four cable entries either metrics or imperial, provide a highly customizable solution meeting a wide range of applications. These including, but not limited to, the Oil and Gas, both onshore and off shore, and Petrochemical industries.
Features
- Twin shaft design, ensuring a complete sealed device: the shaft is splitted in two parts, each fitted and sealed into the body and cover for the best weather insulation even during opening operation
- Suitable for artic application, down to -60° C
- Enhanced flexibility of electrical feedbacks options
- Up to four cable entries available in different sizes
- Enhanced corrosion resistance thanks to Copper free aluminum housing polyester powder coated (SY Series) or 316 stainless steel (SW Series)
- Easy wiring through the terminal PCB board
- NOVA V3 switch option ensures extreme durability and high power switching capabilities
- 4-20 mA position transmitter options
- Single tool opening design, allowing the operator to unscrew the lid by hand after removing the locker
Configure
SY-SW
Box

Switch Quantity

Terminals

Coating

Cable Entry

Visual Position Indicator

Approval Class
Marking

IP Protection Rating

Temperature Range

Material

Specifications
Specifications
Brand
Ambient Temperature Range
- -60° to 80° C (-76° to 176° F)
Approvals & Certifications
- IECEx
- Ex II 2GD Ex db IIC T4/T5/T6 Gb
- Ex tb IIIC T140/T110/T110°C Db
- ATEX
- CCOE
- EAC
- INMETRO
- NEPSI
Cable Entry
- 1/2" NPT
- M20 x 1.5
Enclosure, Body Material
- 316 Stainless Steel
- Aluminum
Environmental Protection
- IP66
- IP68
- NEMA 4
- NEMA 4X
Indication
- 3D Indicator
- Flat Indicator
Output
- 4-20 mA
Switch Quantity
- 2 Switches
- 4 Switches
- 6 Switches
Switch Type
- DPDT
- Electromechanical
- Magnetic Proximity Switch
- SPDT Snap Switch
Temperature Range
- -60° to 105° C (-76° to 221° F)
UL
- Class I Division 1 Groups B,C,D Division 2 Groups A, B, C, D
- Class II Division 1 Groups E,F,G Division 2 Groups F, G
SIL Certificate
- Up to SIL 3 Certified by TÜV
Protection Rating
- IP 66 / 68 10 m for 48 Hours
- Nema 4 4X on request
Documentation
Documentation
Certificate
Dimensional Drawing
Document
- ATEX II2GD Dust Proof (pdf) (210 KB)
- ATEX II2GD Explosion Proof (pdf) (210 KB)
- CCCEx Explosion Proof (pdf) (1.20 MB)
- CCEx Dust Proof (pdf) (1.20 MB)
- CCOE Explosion Proof (pdf) (1.00 MB)
- EAC Hazardous Location (pdf) (4.40 MB)
- ECAS-Ex Explosion Proof/Dust Proof (pdf) (651 KB)
- IEC EX Dust Proof (pdf) (254 KB)
- IEC EX Explosion Proof (pdf) (255 KB)
- INMETRO Dust Proof (pdf) (711 KB)
- INMETRO Explosion Proof (pdf) (711 KB)
- UL Explosion Proof (pdf) (185 KB)
- UL No Spark (pdf) (185 KB)
