High-quality Pressure Transmitter - S-10

Brand: WIKA Instruments Ltd.
WIKA S-10 pressure transmitters are precision engineered to fit most industrial pressure measurement applications.

The compact, rugged design makes these instruments suitable for applications including hydraulics and pneumatics, vacuum, test equipment, liquid level measurement, press control, compressor control, pump protection and numerous other processing and control operations. A wide range of electrical connection and process connection options are available to meet almost any requirement.
Features
  • Measuring ranges from 0 ... 0.1 to 0 ... 1,000 bar.
  • Non-linearity 0.2 % of span (BFSL).
  • Output signals: 4 ... 20 mA, DC 0 ... 10 V, DC 0 ... 5 V and others.
  • Electrical connections: Angular connector form A, circular connector M12 x 1, various cable outlets and others.
  • Zero point and span adjustable via internal potentiometer.
show more
WIKA S-10 pressure transmitters are precision engineered to fit most industrial pressure measurement applications.

The compact, rugged design makes these instruments suitable for applications including hydraulics and pneumatics, vacuum, test equipment, liquid level measurement, press control, compressor control, pump protection and numerous other processing and control operations. A wide range of electrical connection and process connection options are available to meet almost any requirement.
Features
  • Measuring ranges from 0 ... 0.1 to 0 ... 1,000 bar.
  • Non-linearity 0.2 % of span (BFSL).
  • Output signals: 4 ... 20 mA, DC 0 ... 10 V, DC 0 ... 5 V and others.
  • Electrical connections: Angular connector form A, circular connector M12 x 1, various cable outlets and others.
  • Zero point and span adjustable via internal potentiometer.

Specifications

Certifications & Approvals

  • Uzstandard
  • CSA
  • KazInMetr
  • MTSCHS
  • BelGIM
  • UkrSEPRO
  • GOST
  • EAC
  • CE
  • CRN

Environmental Protection

  • IP68
  • IP67
  • IP65

Wetted Materials

  • S13800
  • 316Ti

Material of Construction

  • Flat gasket: VMQ
  • O-ring: NBR
  • Clamping nut/Angular connector: PA
  • Case: 316Ti

Process Connection

  • G ½" male / G ¼" female
  • R ¼"
  • M20 x 1.5
  • 7/16-20 UNF with 74° taper
  • ½" NPT
  • ¼" NPT
  • G ¼" female
  • G ¼" A
  • G 1/2" B
  • G 1/4" B

Measuring Range

  • 0 to 1,000 bar (0 to 15,000 psi)

Output Signal

  • 0-10 vdc
  • 4-20 mA
  • 0-5 Vdc

Typical Applications

  • Hydraulics and pneumatics
  • Test equipment
  • Pump and compressor control
  • Liquid level measurement
