Over Pressurisation Device

Brand: Midland-ACS
A 316L Stainless Steel unit providing protection to downstream equipment from over pressure events.
Features
  • Protection of equipment from regulator failure and over pressure events
  • Specifically Designed for Severe Environments
  • Manifold Mounted Option
  • Auto Shut-Off
  • 1/4 Turn Actuator and on/off Valve Protection
  • Linear Actuator and Control Valve Protection
  • System Instrumentation Equipment Protection
  • Process Valve Stem & Seat Saver
  • Easy Installation
  • 316 Stainless Steel Construction
  • Compliments and Protects ESD & Safety Instrumented System Equipment
  • Ambient Temperature Range: -20° to 80° C (-4° to 176° F) Low Temperature option available
show more
A 316L Stainless Steel unit providing protection to downstream equipment from over pressure events.
Features
  • Protection of equipment from regulator failure and over pressure events
  • Specifically Designed for Severe Environments
  • Manifold Mounted Option
  • Auto Shut-Off
  • 1/4 Turn Actuator and on/off Valve Protection
  • Linear Actuator and Control Valve Protection
  • System Instrumentation Equipment Protection
  • Process Valve Stem & Seat Saver
  • Easy Installation
  • 316 Stainless Steel Construction
  • Compliments and Protects ESD & Safety Instrumented System Equipment
  • Ambient Temperature Range: -20° to 80° C (-4° to 176° F) Low Temperature option available

Specifications

Brand

Ambient Temperature Range

  • -20° to 80° C (-4° to 176° F)

Enclosure, Body Material

  • 316L Stainless Steel

Pressure Range

  • bar: 4 to 8
  • kPa: 400 to 800
  • psi: 58 to 116 (Trip Pressure Range)

Response Time

  • 30 milliseconds (4 to 8 bar)

Supply Pressure - Maximum

  • bar: 20
  • kPa: 2,000
  • psi: 290

Temperature Range

  • -50° to 90° C (-58° to 194° F) Low Temperature Option
