Description
- Adjustable Set Point Range:
- Increasing: 4-28.5 Inches Hg, 102-724 mm Hg
- Decreasing: 1.5-26 Inches Hg, 36-660 mm Hg
- Deadband: 2.5 Inches Hg, 8.0 kPa 0.08 bar
- System Pressure (Maximum):150 psig, 1024.21 kPa, 10.3 bar
- Proof Pressure: 250 psig, 1723.69 kPa, 17.2 bar
- Wetted Materials:
- Pressure Port: 1/4" Male NPT Aluminum
- Diaphragm: Polyimide
- O-Ring: Buna-N
- Relay: SPDT or DPDT
- UL, CSA, CE Mark
Inventory
611VE8000
CCS DUAL-SNAP Vacuum Switch, Hazardous Area, 1/4" NPT Aluminum Port, Polyimide Diaphragm, Buna-N O-Ring, SPDT, Approvals: CE, CRN, CCC, EAC
5 - 7 weeks
$785.00USD
$9.99 Shipping
available on backorder
Configure
611VE8000
O-Ring

Process Connection

Output

Electrical Contacts

Agency Approvals

Paint

Specifications
Specifications
Brand
Adjustment Type
- Factory Set (Pre-Set)
- Field Adjustable
Approvals & Certifications
- ATEX
- CE
- CRN
- CRN - Alberta
- CRN - British Columbia
- CRN - Saskatchewan
- CSA
- cUL
- EMC
- IEC Ex
- PED
- RoHS
- RTN
- UL
Deadband, Approximate
- bar: 0.085
- Inches Hg: 2.5
Diaphragm Material
- Polyimide
Electrical - Free Leads
- 18" (45 cm) Free Leads
- 18" (45 cm) Teflon Leadwire
Electrical Assembly
- Hermetic Seal
Electrical Certification
- ATEX - SIRA Certified for Potentially Explosive Atmospheres. Models 6****Y, II 2 GD Ex D IIC, 08-ATEX-
- c-UL, UL/CSA Explosion-proof: Div. 1, 2 Hermetically Sealed Electrical Assembly P/N 46-1058 (46-1061 for M (DPDT) Model Option), Listed by Both Underwriter's Laboratories, Inc. (File No. E32961) & Canadian Standard Association (CSA) Testing Laboratories
- IECEx - SIRA Certified, SIR 10,0193X (Option Y)
Electrical Connectors
- 1/2" NPT Male
Electrical Contacts
- Gold
- Silver
Electrical Rating
- 1 A at 125 Vac, 50/60 Hz
- 11 A at 125/250 Vac
Enclosure, Body Material
- Aluminum
Environmental Protection
- Hazardous Area
- NEMA 4, 7, 9, 13 / IP54, 66
- NEMA 7
- NEMA 9
NACE & NIST
- NACE MR-0175:2003
NPT Connection
- 1/4" NPT Male
Operating Temperature
- -40° to 86° C (-40° to 187° F)
O-Ring Material
- Buna-N
- Ethylene Propylene (EPR)
- Viton
Process Connection Material
- Aluminum
Proof Pressure
- bar: 17.24
- kPa: 1,724
- psig: 250
Service
- Sweet (Oil & Gas)
Set Point - Decreasing
- Inches Hg: -1.5 to 26
- mm Hg: -38 to 660
Set Point - Increasing
- Inches Hg: -4 to 28.5
- mm Hg: -102 to 724
Switch Type
- DPDT
- SPDT
System Pressure
- bar: 10.3
- kPa: 1,034
- psig: 150
Documentation
Documentation
Data Sheets
Product Manuals
Certifications & Approvals
- Certifications & Approvals - CCS Approval Matrix (pdf) (34 KB)
- Certifications & Approvals - CCS CE Certificate of Declaration (pdf) (225 KB)
- Certifications & Approvals - CCS CRN Approval - Alberta (pdf) (126 KB)
- Certifications & Approvals - CCS CRN Approval - BC (pdf) (67 KB)
- Certifications & Approvals - CCS CRN Approval - Manitoba (pdf) (79 KB)
- Certifications & Approvals - CCS CRN Approval - NWT (pdf) (87 KB)
- Certifications & Approvals - CCS CRN Approval - Saskatchewan (pdf) (263 KB)
- Certifications & Approvals - CCS EMC Directive (pdf) (30 KB)
- Certifications & Approvals - CCS IECEx Certificate of Conformity (pdf) (1.30 MB)
- Certifications & Approvals - CCS LVD - Low Voltage Directive (pdf) (98 KB)
- Certifications & Approvals - CCS PED 2011 (pdf) (94 KB)
- Certifications & Approvals - CCS RoHS/REACH 2012 (pdf) (278 KB)
