PT-L1/L3/L10/L11/L12/L21 Pressure Transmitter

Brand: Automation Products Group Inc. (APG)
Our amplified output pressure transmitters are the economical answer for all applications requiring high accuracy and reliability over a wide range of pressures. The PT-L1/L3/L10/L11/L12/L21 pressure transmitters offer ranges from vacuum to 10,000 psi, all stainless steel construction, high burst pressure, and high acuracy.
Features
  • Cost Effective
  • High overpressure capability
  • Zero and span adjustments
  • Single piece stainless steel process fitting and sensor
show more
Our amplified output pressure transmitters are the economical answer for all applications requiring high accuracy and reliability over a wide range of pressures. The PT-L1/L3/L10/L11/L12/L21 pressure transmitters offer ranges from vacuum to 10,000 psi, all stainless steel construction, high burst pressure, and high acuracy.
Features
  • Cost Effective
  • High overpressure capability
  • Zero and span adjustments
  • Single piece stainless steel process fitting and sensor

Specifications

Accuracy

  • ± 0.5%
  • BFSL ≤ 0.25% of Full Scale
  • Up to ± 1.0% Available on Select Ranges

BSP Connection

  • 1/2" BSPP Male
  • 1/4" BSP Male
  • 3/8" BSPP Male

Cable Length

  • 5 feet (1.5 meters)

Compensated Temperature

  • -17° to 54° C (0° to 130° F)
  • -17° to 85° C (0° to 185° F) - Extended Temperature Compensation Range
  • -40° to 82° C (-40° to 180° F) - Extended Temperature Compensation Range

Cone & Thread Connection

  • High Pressure SnoTrik (M-250C Autoclave Male)

Electrical Connectors

  • 4-Pin Bayonet Connector
  • 4-Pin M12 Micro Connector
  • 6-Pin Bayonet Stainless Steel
  • 6-Pin Circular
  • Pigtail with Cable

Electrical Protection

  • Reverse Polarity

NACE & NIST

  • NIST

NPT Connection

  • 1/4"-18 Female NPT
  • 1/4"-18 Male NPT
  • 1/8"-27 Male NPT

Options

  • Can Assembly - Can Welded to Fitting & Connector
  • Can Assembly - Knurled
  • Can Assembly - Tamper Resistant with Loc-Tite
  • Can Assembly - Tamper Resistant with Weld
  • High Vibration

Output

  • 0-10 Vdc
  • 0-5 Vdc
  • 1-10 Vdc
  • 1-5 Vdc
  • 1-6 Vdc
  • 4-20 mA

Pressure Range

  • bar: 0 to 689.5
  • kPa: 0 to 68,947
  • psi: 0 to 10,000

Pressure Type

  • Absolute
  • Compound (Vacuum & Gauge Pressure)
  • Gauge
  • Sealed Gauge
  • Vacuum

SAE Connection

  • 7/16"-20 SAE Male
  • 7/16"-20 SAE Male Flush Mount

Supply Voltage

  • 0-10 Vdc: 14-33 Vdc
  • 0-5 Vdc, 1-5 Vdc & 1-6 Vdc: 9-33 Vdc
  • 4-20 mA: 10-36 Vdc

UNF/UNC Connection

  • 7/16"-20 UNF Male with Cone

Wetted Materials

  • 316L Stainless Steel
  • 630 Stainless Steel (17-4)
  • 632 Stainless Steel (15-5)
