MPX-E/R Level Sensor

Brand: Automation Products Group - APG
The MPX Series Magnetostrictive Level Sensor provides highly accurate and repeatable level readings in a wide variety of liquid level measurement applications. The MPX-R’s large, buoyant, and robust float allows it to be used in harsh applications where fouling or buildup might otherwise be of concern. The MPX-E’s lighter weight design allows it to be used in applications where space is limited.
Features
  • Class 1 Division 1 Groups C & D, Class 1 Zone 1, Class 1 Zone 2
  • Highly accurate and repeatable readings
  • 4-20 mA, RS-485 (Modbus RTU) output
  • Rugged and reliable, lengths up to 32 feet (9.75 m)
  • Dual level (interface) measurement
  • Tank volume/level, strapping table
show more
The MPX Series Magnetostrictive Level Sensor provides highly accurate and repeatable level readings in a wide variety of liquid level measurement applications. The MPX-R’s large, buoyant, and robust float allows it to be used in harsh applications where fouling or buildup might otherwise be of concern. The MPX-E’s lighter weight design allows it to be used in applications where space is limited.
Features
  • Class 1 Division 1 Groups C & D, Class 1 Zone 1, Class 1 Zone 2
  • Highly accurate and repeatable readings
  • 4-20 mA, RS-485 (Modbus RTU) output
  • Rugged and reliable, lengths up to 32 feet (9.75 m)
  • Dual level (interface) measurement
  • Tank volume/level, strapping table
58 models matching criteria
MPX-E4-CN-PS2B-54
APG MPX Magnetostrictive Sensor, 0.5" Modbus, 150# NPT Plug, Size 2, Small Housing, Slide, 316 SST, 54" View More
  • MPX: Explosion Proof Continuous Float Level Transmitter (Magnetostrictive)
  • E: Stem Type: 1/2” Diameter, 316L SS
  • 4: Output: Modbus RTU, surge/lightning protection
  • C: Float 1: 316L SS Cylindrical (0.65 SG)
  • N: Float 2: Not Required
  • P2: Process Connection: 2”NPT Plug, 150#
  • S: Mounting Connection: Slide with Compression Fitting (adjustable)
  • B: Stem Material: 316L SS
  • 54: Stem Length in inches
  • Safety Rating: CSA Class 1 Div 1 Groups C & D

**Crate required for Transport**
3 - 4 weeks
Non-Cancellable / Non-Refundable
$1,310.92 USD
$15.51 Shipping
MPX-E2-FN-P1.5SB-14.00-S-N1A1
APG MPX Magnetostrictive Sensor, 4-20 mA, 1.5" NPT Mt, Slide, 316L SST, 14" Stem, NCNR View More
  • MPX: Explosion Proof Continuous Float Level Transmitter (Magnetostrictive)
  • E: Stem Type: 1/2” Diameter
  • 2: Output: Single float, 4-20 mA (loop powered, 2 wire)
  • F: Float 1: 316 SS 3A Cylindrical (0.5 SG)
  • N: Float 2: Not Required
  • P1.5: Process Connection: 1.5”NPT Plug, 150#
  • S: Mounting Connection: Slide
  • B: Stem Material: 316L SS
  • 14.00: Stem Length in inches (356 mm)
  • S: Float Stop: 1 Piece with set screw, Bottom only
  • N1A1: *Setpoint Type: Standard Locations
    • *4mA Set Point: 0.00 Inches from the Bottom (0 mm)
    • *20mA Set Point: 8.00 Inches from the Bottom (203 mm)
      • End Plug: Flat End (standard)
      • Float Stop: 1 piece with set screw, bottom only.
  • Safety Rating: CSA Class 1 Div 1 Groups C & D
3 - 5 weeks
Non-Cancellable / Non-Refundable
$1,325.65 USD
$15.51 Shipping
MPX-E4A-CN-P2SB-54
APG MPX Magnetostrictive Sensor, Modbus RTU, 150# NPT Plug, Size 2, Small Housing, Slide, 316 SST, 54" View More
  • MPX: Explosion Proof Level Sensor (Magnetostrictive)
  • E: Stem Type: 1/2” Diameter, 316L SS
  • 4A: Output: Modbus RTU, surge/lightning protection
  • C: Float 1: 1.38H x 1.63W 316L SS Cylindrical (0.65 SG)
  • N: Float 2: Not Required
  • P2: Process Connection: 2”NPT Plug, 150#
  • S: Mounting Connection: Slide with Compression Fitting (adjustable)
  • B: Stem Material: 316L SS
  • 54: Stem Length in inches
  • Safety Rating: CSA Class 1 Div 1 Groups C & D

**Crate required for Transport**
3 - 4 weeks
Non-Cancellable / Non-Refundable
$1,331.86 USD
$15.51 Shipping
MPX-E4A-CN-P2SB-54-T6
APG MPX Magnetostrictive Sensor, Modbus RTU, 150# NPT Plug, Size 2, Small Housing, Slide, 316 SST, 54" View More
  • MPX: Explosion Proof Level Sensor (Magnetostrictive)
  • E: Stem Type: 1/2” Diameter, 316L SS
  • 4A: Output: Modbus RTU, surge/lightning protection
  • C: Float 1: 1.38H x 1.63W 316L SS Cylindrical (0.65 SG)
  • N: Float 2: Not Required
  • P2: Process Connection: 2”NPT Plug, 150#
  • S: Mounting Connection: Slide with Compression Fitting (adjustable)
  • B: Stem Material: 316L SS
  • 54: Stem Length in inches
  • T6: 1K RTD at 6" from bottom. ±1°C
  • Safety Rating: CSA Class 1 Div 1 Groups C & D

**Crate required for Transport**
3 - 4 weeks
$1,331.86 USD
$15.51 Shipping
MPX-E4A-CN-P2SB-54-T6-N1A1-S
APG MPX Magnetostrictive Sensor, Modbus RTU, 150# NPT Plug, Size 2, Small Housing, Slide, 316 SST, 54" View More
  • MPX: Explosion Proof Level Sensor (Magnetostrictive)
  • E: Stem Type: 1/2” Diameter, 316L SS
  • 4A: Output: Modbus RTU, surge/lightning protection
  • C: Float 1: 1.38H x 1.63W 316L SS Cylindrical (0.65 SG)
  • N: Float 2: Not Required
  • P2: Process Connection: 2”NPT Plug, 150#
  • S: Mounting Connection: Slide with Compression Fitting (adjustable)
  • B: Stem Material: 316L SS
  • 54: Stem Length in inches
  • T6: 1K RTD at 6" from bottom. ±1°C
  • Safety Rating: CSA Class 1 Div 1 Groups C & D

**Crate required for Transport**
3 - 4 weeks
Non-Cancellable / Non-Refundable
$1,331.86 USD
$15.51 Shipping
MPX-E4-CN-P2SB-56-T6
APG MPX Magnetostrictive Sensor, Modbus RTU, 150# NPT Plug, Size 2, Small Housing, Slide, 316 SST, 56" View More
  • MPX: Explosion Proof Level Sensor (Magnetostrictive)
  • E: Stem Type: 1/2” Diameter, 316L SS
  • 4A: Output: Modbus RTU, surge/lightning protection
  • C: Float 1: 1.38H x 1.63W 316L SS Cylindrical (0.65 SG)
  • N: Float 2: Not Required
  • P2: Process Connection: 2”NPT Plug, 150#
  • S: Mounting Connection: Slide with Compression Fitting (adjustable)
  • B: Stem Material: 316L SS
  • 56: Stem Length in inches
  • T6: 1K RTD at 6" from bottom. ±1°C
  • Safety Rating: CSA Class 1 Div 1 Groups C & D

**Crate required for Transport**
3 - 4 weeks
Non-Cancellable / Non-Refundable
$1,334.19 USD
$15.51 Shipping
MPX-E2-CN-P2SB-62-N-N2A1-S-0.00|56.00
APG MPX Magnetostrictive Sensor, 0.5", 4-20 mA, 2" NPT Plug, 62", Welded, Bridal Install/Top View More
  • MPX: Explosion Proof Continuous Float Level Transmitter (Magnetostrictive)
  • E: Stem Type: 1/2” Diameter
  • 2: Output: Single float, 4-20 mA (loop powered, 2 wire)
  • C: Float 1: 316L SS Cylindrical (0.65 SG)
  • N: Float 2: Not Required
  • P2: Process Connection: 2”NPT Plug, 150#
  • S: Mounting Connection: Welded
  • B: Stem Material: 316L SS
  • 62: Stem Length in inches
  • Safety Rating: CSA Class 1 Div 1 Groups C & D

End Plug: Flat End (standard)

Float Stop: 1 Piece with set screw, bottom only

Setpoint Type: standard locations

4mA Set Point: 0" from the bottom (0mm)

20mA Set Point 56" from the bottom (1422mm)



**Crate required for Transport**

3 - 5 weeks
Non-Cancellable / Non-Refundable
$1,414.86 USD
$15.51 Shipping
MPX-E2-AN-P2TB-48
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 2" Round 316L SST Float (0.65 SG), 2" MNPT (Welded, Fixed), 48 View More
  • MPX: Explosion Proof Continuous Float Level Transmitter (Magnetostrictive)
  • E: Stem Type: 1/2” Diameter
  • 2: Output: Single float, 4-20 mA (loop powered, 2 wire)
  • A: Float 1: 316L SS Round (0.65 SG)
  • N: Float 2: Not Required
  • P2: Process Connection: 2”NPT Plug, 150#
  • T: Mounting Connection: 150# Plug Mount Outside, 2" NPT Welded at Coupler Top
  • B: Stem Material: 316L SS
  • 48: Stem Length in inches
  • Safety Rating: CSA Class 1 Div 1 Groups C & D
3 - 5 weeks
Non-Cancellable / Non-Refundable
$1,431.92 USD
$15.51 Shipping
MPX-E2-CN-P2WB-30
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 1.38" H x 1.63" D Cylindrical 316L SST Float (0.61 SG), 2" MNPT (Welded, Fixed), 30 View More
  • MPX: Explosion Proof Continuous Float Level Transmitter (Magnetostrictive)
  • E: Stem Type: 1/2” Diameter
  • 2: Output: Single float, 4-20 mA (loop powered, 2 wire)
  • C: Float 1: 316L SS Cylindrical (0.65 SG)
  • N: Float 2: Not Required
  • P2: Process Connection: 2”NPT Plug, 150#
  • W: Mounting Connection: Welded (fixed)
  • B: Stem Material: 316L SS
  • 30: Stem Length in inches
  • Safety Rating: CSA Class 1 Div 1 Groups C & D
3 - 5 weeks
Non-Cancellable / Non-Refundable
$1,444.33 USD
$15.51 Shipping
MPX-E4-CN-P2SB-52
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (316L SST), Modbus RTU Output, 1.38" H x 1.63" D Cylindrical 316L SST Float (0.61 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 124 View More
  • MPX: Explosion Proof Continuous Float Level Transmitter (Magnetostrictive)
  • E: Stem Type: 1/2” Diameter, 316L SS
  • 4: Output: Modbus RTU, surge/lightning protection
  • C: Float 1: 316L SS Cylindrical (0.65 SG)
  • N: Float 2: Not Required
  • P2: Process Connection: 2”NPT Plug, 150#
  • S: Mounting Connection: Slide with Compression Fitting (adjustable)
  • B: Stem Material: 316L SS
  • 52: Stem Length in inches
  • Safety Rating: CSA Class 1 Div 1 Groups C & D

**Crate required for Transport**
3 - 5 weeks
Non-Cancellable / Non-Refundable
$1,458.30 USD
$15.51 Shipping

Specifications

Accuracy

  • ± 0.05% of Span

Approvals & Certifications

  • CSA Class I, Division 1, Groups C, D T4 (Ta 84° C) Class I, Zone 1, AEx D IIB T4 Class I, Zone 2, AE

Communication

  • Interface with RS-485 Modbus RTU
  • Interface with RST-4100 Programming Module

Electrical Connectors

  • Terminal Block

Enclosure, Body Material

  • Aluminum, Epoxy Coated

Environmental Protection

  • IP65
  • IP66
  • NEMA 4X

Flange Size - 1" (DN25)

  • 1" (DN25) - 150#

Flange Size - 1-1/2" (DN40)

  • 1-1/2" (DN40) - 150#

Flange Size - 2" (DN50)

  • 2" (DN50) - 150#

Flange Size - 2-1/2" (DN65)

  • 2-1/2" (DN65) - 150#

Flange Size - 3" (DN80)

  • 3" (DN80) - 150#

Flange Size - 3-1/2" (DN90)

  • 3-1/2" (DN90) - 150#

Flange Size - 4" (DN100)

  • 4" (DN100) - 150#

Flange Size - 5" (DN125)

  • 5" (DN125) - 150#

Flange Size - 6" (DN150)

  • 6" (DN150) - 150#

NPT Connection

  • 1" NPT Male
  • 1-1/2" NPT Male
  • 2" NPT Male
  • 2-1/2" NPT Male
  • 3" NPT Male
  • 3-1/2" NPT Male
  • 4" NPT Male
  • 5" NPT Male
  • 6" NPT Male

Operating Temperature

  • -40° to 85° C (-40° to 185° F)

Output

  • 4-20 mA

Resolution

  • 0.04" (1 mm)

Sensor, Probe Style

  • Float

Supply Voltage

  • 12-24 Vdc

Tri-Clamp Connection

  • 1" Sanitary Clamp
  • 1-1/2" Sanitary Clamp
  • 2" Sanitary Clamp
  • 2-1/2" Sanitary Clamp
  • 3" Sanitary Clamp
  • 3-1/2" Sanitary Clamp
  • 4" Sanitary Clamp
  • 5" Sanitary Clamp
  • 6" Sanitary Clamp
