L1105 (COB) Explosion-Proof LED Light

Brand: Top Hi-Tech Inc.
  • Volt.: 24 V / 110 V / 120 V / 220 V / 277 V / 480 V AC
  • Watt.: 40 W / 60 W (Watts of 24 V are different)
  • Amps: 40 W (0.08 ~ 1.67 A) / 60 W (0.13 ~ 2.5 A)
  • Frequency: 50 Hz / 60 Hz
  • Power Factor: cos ≧ 0.9 / cos ≧ 0.87(480 V)
Degree of Protection - IP68 / NEMA 6P
IECEx Certification
  • Ex d IIB + H2 T6...T4 Gb
  • Ex tb IIIC T108˚ C Db
ATEX Certification
  • II 2 G Ex d IIB + H2 T6...T4 Gb
  • II 2 D Ex tb IIIC T108˚ C Db
UL Certification
  • UL844 - Class I, Division 1 (Groups B, C and D) / Class I, Division 2 (Groups A, B, C and D) /  Class II, Division 1 (Groups E, F and G) / Class III
  • UL1598
ABS&CR Certification
  • II 2 G Ex d IIB + H2 T5...T4 Gb
  • II 2 D Ex tb IIIC T108˚ C Db
TS Certification
  • Ex d IIB + H2 T5 Gb
  • Ex tb IIIC T110˚ C Db
GB Certification
  • Ex d IIB + H2 T5...T4 Gb
  • DIP A21 TA T108˚ C
Features
  • Service life up to 60,000 hours
  • Salt spray 1000 hrs passed
  • Tank veiwer mounting available
 Applicable Location:
  • Zone 1 & Zone 2
  • Zone 21 & Zone 22
  • Class I, Division 1 (Groups B, C and D)
  • Class I, Division 2 (Groups A, B, C and D)
  • Class II, Division 1 (Groups E, F and G)
  • Class III
show more
Images are representations only.
  • Volt.: 24 V / 110 V / 120 V / 220 V / 277 V / 480 V AC
  • Watt.: 40 W / 60 W (Watts of 24 V are different)
  • Amps: 40 W (0.08 ~ 1.67 A) / 60 W (0.13 ~ 2.5 A)
  • Frequency: 50 Hz / 60 Hz
  • Power Factor: cos ≧ 0.9 / cos ≧ 0.87(480 V)
Degree of Protection - IP68 / NEMA 6P
IECEx Certification
  • Ex d IIB + H2 T6...T4 Gb
  • Ex tb IIIC T108˚ C Db
ATEX Certification
  • II 2 G Ex d IIB + H2 T6...T4 Gb
  • II 2 D Ex tb IIIC T108˚ C Db
UL Certification
  • UL844 - Class I, Division 1 (Groups B, C and D) / Class I, Division 2 (Groups A, B, C and D) /  Class II, Division 1 (Groups E, F and G) / Class III
  • UL1598
ABS&CR Certification
  • II 2 G Ex d IIB + H2 T5...T4 Gb
  • II 2 D Ex tb IIIC T108˚ C Db
TS Certification
  • Ex d IIB + H2 T5 Gb
  • Ex tb IIIC T110˚ C Db
GB Certification
  • Ex d IIB + H2 T5...T4 Gb
  • DIP A21 TA T108˚ C
Features
  • Service life up to 60,000 hours
  • Salt spray 1000 hrs passed
  • Tank veiwer mounting available
 Applicable Location:
  • Zone 1 & Zone 2
  • Zone 21 & Zone 22
  • Class I, Division 1 (Groups B, C and D)
  • Class I, Division 2 (Groups A, B, C and D)
  • Class II, Division 1 (Groups E, F and G)
  • Class III

Specifications

Approvals & Certifications

  • ABS
  • ATEX
  • cULus
  • GB
  • IECEx
  • TS

Beam

  • Beam Angle ≥ 110°

Enclosure, Body Material

  • Aluminum Alloy

Environmental Protection

  • IP67
  • IP68
  • NEMA 6
  • NEMA 6P

Frequency

  • 50/60 Hz

Lens

  • Tempered Glass - IEC Standards Impact Resistant > 4 Joule

Lumens

  • Lum/Watt: ≥ 100 (Cool White), ≥ 90 (Warm White)

Operating Temperature

  • -20° to 40° C (-4° to 104° F), UL: -40° to 40° C (-40° to 104° F)

Screw Material

  • Stainless Steel

Voltage

  • 120 V / 277 V / 480 V AC

Wattage

  • 40 W / 60 W
