Images are representations only.

Model 66 Pneumatic Stainless Steel Regulator

Brand: Fairchild Industrial Products
The Rotork Fairchild Model 66 is a stainless steel pressure regulator for high performance applications with corrosive environments and/or high temperatures.

The Model 66 Stainless steel housing and internals, along with its fluorocarbon elastomers are compatible with a wide range of corrosive materials and difficult operating environments.

The Fairchild Model 66 pneumatic regulator features control sensitivity of 1" water column to deliver consistent and reliable precision accuracy to maintain your desired set point regardless of system pressure changes or conditions.

The Fairchild Model 66 pressure regulator will handle a 500 psi, 35 BAR maximum supply pressure and offers five (5) set point pressure ranges from 0-10 psi, 0-0.7 BAR, 0-70 kPa up to 2-150 psi, 0.15-10 BAR, 15-1,000 kPa.
Features
  • Stainless Steel and Fluorocarbon
  • Control sensitivity to 1" water column
  • Large Control Diaphragm area
  • Valve Damper system
  • Line or Panel Mounting
show more
The Rotork Fairchild Model 66 is a stainless steel pressure regulator for high performance applications with corrosive environments and/or high temperatures.

The Model 66 Stainless steel housing and internals, along with its fluorocarbon elastomers are compatible with a wide range of corrosive materials and difficult operating environments.

The Fairchild Model 66 pneumatic regulator features control sensitivity of 1" water column to deliver consistent and reliable precision accuracy to maintain your desired set point regardless of system pressure changes or conditions.

The Fairchild Model 66 pressure regulator will handle a 500 psi, 35 BAR maximum supply pressure and offers five (5) set point pressure ranges from 0-10 psi, 0-0.7 BAR, 0-70 kPa up to 2-150 psi, 0.15-10 BAR, 15-1,000 kPa.
Features
  • Stainless Steel and Fluorocarbon
  • Control sensitivity to 1" water column
  • Large Control Diaphragm area
  • Valve Damper system
  • Line or Panel Mounting
Close

Specifications

Brand

Actuator Type

  • Knob Adjust
  • Screw

Ambient Temperature Range

  • -28° to 149° C (-20° to 300° F)

Bonnet Material

  • Aluminum

BSP Connection

  • 1/2" BSPP Female
  • 1/2" BSPT Female
  • 1/4" BSPP Female
  • 1/4" BSPT Female
  • 3/8" BSPP Female
  • 3/8" BSPT Female

Diaphragm Material

  • Viton with Teflon on Control Side

Elastomers

  • Fluorocarbon

Enclosure, Body Material

  • Stainless Steel

Exhaust Capacity - Relieving Units Only

  • 1 scfm (1.7 m³/hour) where Downstream Pressure is psig: 5 (bar: 0.35, kPa: 35) Above psig: 20 (bar: 1.5, kPa: 150) Set Point

Flow Capacity

  • 17 scfm (28.9 m³/hour) at psig: 100 (bar: 7, kPa: 700) Supply & psig: 20 (bar: 1.5, kPa: 150) Set Point

Mounting

  • Panel Mount

NPT Connection

  • 1/2" NPT Female
  • 1/4" NPT Female
  • 3/8" NPT Female

Pressure Range

  • bar: 0 to 10
  • kPa: 0 to 1,000
  • psig: 0 to 150

Relief

  • Non-Relieving - Aluminum Bonnet
  • Relieving

Sensitivity

  • 1 inH₂O (2.54 cm)

Supply Pressure - Maximum

  • bar: 35
  • kPa: 3,500
  • psig: 500

Supply Pressure Effect

  • Less than psig: 0.1 (bar: 0.007, kPa: 0.7) for psig: 25 (bar: 1.7, kPa: 170) Change in Supply Pressure

Trim Material

  • Stainless Steel
  • Teflon

Vent

  • Straight
  • Tapped Exhaust
