Ring RTD

Brand: Pyromation
The ring type assembly pictured below has the RTD element embedded into a brass ring. Various ring sizes are available to measure the surface temperature of nozzles, extruder barrels, die heads, molds, and many other applicable surfaces.

This assembly is supplied standard using a 100 Ω platinum element with a temperature coefficient of 0.003 85 °C-1 (IEC Class B).
show more
The ring type assembly pictured below has the RTD element embedded into a brass ring. Various ring sizes are available to measure the surface temperature of nozzles, extruder barrels, die heads, molds, and many other applicable surfaces.

This assembly is supplied standard using a 100 Ω platinum element with a temperature coefficient of 0.003 85 °C-1 (IEC Class B).

Specifications

Brand

Material of Construction

  • Ring: Brass
  • Element: Platinum

Element Connection

  • 2-wire
  • 3-wire

Ring Size (ID x W x L)

  • 0.20" x 3/8" x 5/8"
  • 0.33" x 5/8" x 7/8"
  • 0.44" x 5/8" x 7/8"

Leadwire Insulationn

  • Fiberglass
  • Fluoropolymer
  • Polyimide
