KE Series Electric Actuator

Brand: A-T Controls, Inc.
Request Information
Favorite
The TRIAC® KE Series electric actuators are the perfect match for small resilient or high-performance butterfly valves and dampers because of the self-locking worm drive and low profile that makes them ideal for tight spaces.

The KE Series actuators are used to control rotary valves, such as butterfly valves, ball valves, plug valves, etc.

Widely used in applications such as petroleum, chemical, water treatment, ship, paper, power stations, heating supply, building automation, light industry, etc.
Features
  • Convex Lens Visual Position Indicator Makes it Easier to Observe without Water Collecting on the Surface of the Indicator
  • Anti-condensation Heater and Thermostat
  • Two Auxiliary Limit Switches
  • Self-locking Gear Train
  • Manual Override with Wrench
  • Available Motor Voltages: 12VDC, 24VDC, 120VAC and 220VAC
  • Optional 4-20mA and 0-10 VDC Proportional Control
  • 8000 Cycles at 50% Duty Cycle
show more
The TRIAC® KE Series electric actuators are the perfect match for small resilient or high-performance butterfly valves and dampers because of the self-locking worm drive and low profile that makes them ideal for tight spaces.

The KE Series actuators are used to control rotary valves, such as butterfly valves, ball valves, plug valves, etc.

Widely used in applications such as petroleum, chemical, water treatment, ship, paper, power stations, heating supply, building automation, light industry, etc.
Features
  • Convex Lens Visual Position Indicator Makes it Easier to Observe without Water Collecting on the Surface of the Indicator
  • Anti-condensation Heater and Thermostat
  • Two Auxiliary Limit Switches
  • Self-locking Gear Train
  • Manual Override with Wrench
  • Available Motor Voltages: 12VDC, 24VDC, 120VAC and 220VAC
  • Optional 4-20mA and 0-10 VDC Proportional Control
  • 8000 Cycles at 50% Duty Cycle
Close
Close

Specifications

Brand

Actuator Type

  • 2-Position Control - Open/Close
  • Modulating

Conduit Connection

  • 2 x 1/2” NPT

Environmental Protection

  • Weather-Proof IP67 Electric Actuator

Input

  • 4-20 mA

Materials of Construction

  • Powder-Coated Die Cast Aluminum

Motor Voltages

  • 110/120 Vac / 1-Phase
  • 12 Vdc
  • 220 Vac / 1-Phase
  • 24 Vac / 1-Phase
  • 24 Vdc

Mounting

  • ISO 5211 (F05/F07/F10/F12)

Output

  • 0-10 Vdc

Torque

  • 1,700 In/Lbs
  • 3,500 In/Lbs
  • 440 In/Lbs
  • 880 In/Lbs
