HU Pressure Transmitter

Brand: Automation Products Group Inc. (APG)
The Hammer Union Pressure Transmitter is an extremely rugged pressure transmitter designed specifically for the harsh environment in the oil patch including mud logging and measurement while drilling.
Features
  • Ranges to 20,000 psi
  • 4-20 mA or 0-5 VSC output
  • 1502 or 2202 fitting
  • Exceptional shock and vibration resistance
  • ±0.25% accuracy of full scale
  • CSA/ATEX/IEC Approved
show more
The Hammer Union Pressure Transmitter is an extremely rugged pressure transmitter designed specifically for the harsh environment in the oil patch including mud logging and measurement while drilling.
Features
  • Ranges to 20,000 psi
  • 4-20 mA or 0-5 VSC output
  • 1502 or 2202 fitting
  • Exceptional shock and vibration resistance
  • ±0.25% accuracy of full scale
  • CSA/ATEX/IEC Approved
49 models matching criteria
HU-L24-IS-15K-PSIS-E15-P36-K0-B0
APG Hammer Union Pressure Transducer, 0-15,000 psi, 4-20 mA, 6-Pin Bayonet, Inconel, 1502 Welded
4 In Stock
$1,341.73 USD $742.45USD
$7.89 Shipping
HU-L24-IS-5K-PSIS-E15-P36-K0-B0
APG Hammer Union Pressure Transducer, 0-5000 psi, 4-20 mA, 6-Pin Bayonet, Inconel, 1502Welded
3 In Stock
$1,341.73 USD $848.29USD
$7.89 Shipping
HU-L24-IS-10K-PSIS-E15-P36-K0-B0
APG Hammer Union Pressure Transducer, 0-10,000 psi, 4-20 mA, 6-Pin Bayonet, Inconel, 1502 Welded
1 In Stock
$1,325.36USD
$7.89 Shipping
HU-L24-IS-15K-PSIS-E15-P34-K0-B0
APG Hammer Union Pressure Transducer, 0-15,000 psi, 4-20 mA, 6-Pin Bayonet, Inconel, 1502 Large
1 In Stock
$1,362.48USD
$7.89 Shipping
HU-L24-IS-10K-PSIS-E19-P36-K0-B0
APG Hammer Union Pressure Transducer, 0-10,000 psi, 4-20 mA, MS3102E-14S-2P, Inconel, 1502 Welded
3 - 5 weeks
$1,325.36USD
$7.89 Shipping
HU-L24-IS-10K-PSIS-E34-P36-K0-B0
APG Hammer Union Pressure Transducer, 0-10,000 psi, 4-20 mA, 6-Pin Bayonet, Inconel, 1502 Welded
2 - 4 weeks
$1,325.36USD
$7.89 Shipping
HU-L24-IS-15K-PSIS-E19-P36-K0-B0
APG Hammer Union Pressure Transducer, 0-15,000 psi, 4-20 mA, MS3102E-14S-2P, Inconel, 1502 Welded
3 - 5 weeks
$1,325.36USD
$7.89 Shipping
HU-L24-IS-15K-PSIS-E27-P36-K0-B0
APG Hammer Union Pressure Transducer, 0-15,000 psi, 4-20 mA, 6-Pin Bayonet SST, Inconel,1502 Welded
3 - 5 weeks
$1,325.36USD
$7.89 Shipping
HU-L24-IS-5K-PSIS-E34-P36-K0-B0
APG Hammer Union Pressure Transducer, 0-5000 psi, 4-20 mA, 6-Pin Bayonet, Inconel, 1502 Welded
2 - 5 weeks
$1,325.36USD
$7.89 Shipping
HU-L24-IS-20K-PSIS-E56-P36-K0
APG Hammer Union Pressure Transducer, 0-20,000 psi, Sealed, l4-20 mA, 4Pin Minifast, 1502 Welded
3 - 5 weeks
Non-Cancellable / Non-Refundable
$1,325.36USD
$7.89 Shipping

Specifications

Accuracy

  • ± 0.25% BFSL

Approvals & Certifications

  • ATEX
  • CSA Class I, Division 1, Groups C, D
  • IEC Ex

Burst Pressure

  • 3 times Full Scale or Limit of WECO Fitting, whichever is Less

Compensated Temperature

  • -40° to 65° C (-40° to 150° F)

Electrical Connectors

  • 4-Pin "Mini" Style
  • 4-Pin MS3102
  • 5-Pin "Mini" Style
  • 6-Pin Bayonet Stainless Steel

Input Power

  • Vdc: 10-30

Insulation Resistance

  • > 100 MegaOhms at 500 Vac at 70° C (158° F)

NACE & NIST

  • NACE MR-0175, ISO 15156

Operating Temperature

  • -40° to 85° C (-40° to 185° F)

Output

  • 0 to 5 Vdc: 110 mA Inrush Current, 3.5 mA Operating Current
  • 3-30 mA Max

Overpressure & Static Pressure Limits

  • 1.5 x Full Scale or Limit of WECO Fitting, whichever is Less.

Pressure Range

  • bar: 0 to 1,034
  • kPa: 0 to 103,421
  • psig: 0 to 15,000

Process Connection - Other

  • Small/Large Hammer Union 2202 WECO Fitting
  • Small/Large Welded Hammer Union 1502 WECO Fitting

Shunt Calibration

  • 100% of Full Scale Output

Span & Zero Effect

  • ± 0.026% of Full Scale Output / °C (± 0.01% of Full Scale Output / °F)

Storage Temperature

  • -50° to 120° C (-58° to 248° F)

Wetted Materials

  • Inconel®
