FD9 Series 600# Flanged Automated Ball Valve

Brand: A-T Controls, Inc.
Triac® FD9 Series Flanged Ball Valves feature a direct mount automation pad.

The high-quality investment castings feature a fully machined bore.

Superior live-loaded packing system is accomplished with Belleville washers, "V" ring packing and a unique pyramidal stem seal design.

This advanced sealing system provides for protection against stem leaks experienced by ordinary ball valves.
Features
  • Design: 2-Piece Flanged Fireproof, Direct mount
  • Size: 1/2" to 2"
  • Port: Full
  • Direct Mount: Yes
  • Pyramidal Stem Packing: Yes
  • Materials of Construction:
    • Body: WCB
    • Trim: 316 Stainless Steel
    • Available Seats: CTFE, PTFE, 50/50%
  • End Connections: 600# Flanged End
  • Maximum Pressure Rating: 740 psi
  • Actuator Type:
    • Pneumatic: Double Acting or Spring Return
    • Electric: On/Off or Modulating
show more
Triac® FD9 Series Flanged Ball Valves feature a direct mount automation pad.

The high-quality investment castings feature a fully machined bore.

Superior live-loaded packing system is accomplished with Belleville washers, "V" ring packing and a unique pyramidal stem seal design.

This advanced sealing system provides for protection against stem leaks experienced by ordinary ball valves.
Features
  • Design: 2-Piece Flanged Fireproof, Direct mount
  • Size: 1/2" to 2"
  • Port: Full
  • Direct Mount: Yes
  • Pyramidal Stem Packing: Yes
  • Materials of Construction:
    • Body: WCB
    • Trim: 316 Stainless Steel
    • Available Seats: CTFE, PTFE, 50/50%
  • End Connections: 600# Flanged End
  • Maximum Pressure Rating: 740 psi
  • Actuator Type:
    • Pneumatic: Double Acting or Spring Return
    • Electric: On/Off or Modulating
8 models matching criteria
A-T CONTROLS Series FD9 Ball Valve, Direct Mt. Carbon Steel, 600# Flange, 2",CTFE View More
  • F: Firesafe
  • D9: Direct Mount Flanged
  • C: Carbon Steel Body
  • F6: 600# Flanged End
  • 0200: 2" Valve Size
  • C: CTFE Seats
  • XX: No Specials
2 - 4 weeks
$936.72USD
$19.16 Shipping
A-T CONTROLS Series FD9 Ball Valve, Split Body 600# Flange, 1", Electric On/Off, RTFE View More
  • F: Firesafe
  • D9: Direct Mount Flanged
  • 6C: 600# Flanged Ends, CTFE Seats (15% CS Powder/85% TFE Seats)
  • 100: 1-Inch Valve
  • XEB1: Actuator-Electric On/Off 690 In-Lbs,115 VAC
  • XX: No Specials
2 - 4 weeks
$1,488.00USD
$19.16 Shipping
A-T CONTROLS Series FD9 Ball Valve, Split Body 600# Flange, 2", Spring Return,w/CTFE Seats View More
  • F: Firesafe
  • D9: Direct Mount Flanged
  • 6C: 600# Flanged Ends, CTFE Seats (15% CS Powder/85% TFE Seats)
  • 200: 2-Inch Valve
  • 2R5S: Actuator-Pneumatic 2R200 Spring Return
  • X: No Specials
  • X: No Specials
2 - 4 weeks
$1,586.02USD
$19.16 Shipping
A-T CONTROLS Series FD9 Ball Valve, Split Body 600# Flange, 1", Electric On/Off, RTFE, 24 VDC View More
  • F: Firesafe
  • D9: Direct Mount Flanged
  • 6C: 600# Flanged Ends, CTFE Seats (15% CS Powder/85% TFE Seats)
  • 100: 1-Inch Valve
  • XEB1: Actuator-Electric On/Off 690 In-Lbs
  • R: 24 VDC
  • X: No Specials
2 - 4 weeks
$1,758.48USD
$19.16 Shipping
A-T CONTROLS Series FD9 Ball Valve, Split Body 600# Flange, 1", Electric On/Off, RTFE, 12 VDC View More
  • F: Firesafe
  • D9: Direct Mount Flanged
  • 6C: 600# Flanged Ends, CTFE Seats (15% CS Powder/85% TFE Seats)
  • 100: 1-Inch Valve
  • XEB1: Actuator-Electric On/Off 690 In-Lbs
  • W: 12 VDC
  • X: No Specials
2 - 4 weeks
$1,758.48USD
$19.16 Shipping
A-T CONTROLS Series FD9 Ball Valve, Split Body 600# Flange, 2", Electric On/Off,w/CTFE Seats View More
  • F: Firesafe
  • D9: Direct Mount Flanged
  • 6C: 600# Flanged Ends, CTFE Seats (15% CS Powder/85% TFE Seats)
  • 200: 2-Inch Valve
  • WEB1: Actuator-Electric On/Off 690 In-Lbs, 120 VAC
  • XX: No Specials
2 - 4 weeks
$2,125.50USD
$19.16 Shipping
A-T CONTROLS Series FD9 Ball Valve, Split Body 600# Flange, 2", Electric On/Off,w/CTFE Seats View More
  • F: Firesafe
  • D9: Direct Mount Flanged
  • 6C: 600# Flanged Ends, CTFE Seats (15% CS Powder/85% TFE Seats)
  • 200: 2-Inch Valve
  • XCB1: XC-00690 In-Lbs, 120 VAC
  • XX: No Specials
2 - 4 weeks
$2,183.73USD
$19.16 Shipping
A-T CONTROLS Series FD9 Ball Valve, Split Body 600# Flange, 2", Spring Return,Positioner,w/CTFESeats View More
  • F: Firesafe
  • D9: Direct Mount Flanged
  • 6C: 600# Flanged Ends, CTFE Seats (15% CS Powder/85% TFE Seats)
  • 200: 2-Inch Valve
  • 2R5S: Actuator-Pneumatic 2R200 Spring Return
  • E: EPR-1000 Electro-Pneumatic Positioner, 4-20mA @ 24VDC Input
  • X: No Specials
2 - 4 weeks
$2,471.89USD
$19.16 Shipping
